The secret is in the blank design
|
|
Low-modulus graphite is used for the tip section aiding smooth
hooking, mid modulus and low-modulus composite for the belly
section provide both tensile strength and elasticity, and
high-modulus kevlar graphite provide the butt section which is
powerful enough to fight a fish and bring it up to the surface.
For example the 70MH rod is targeted as fish of 20kg class like
Dolphin Tuna and Skip Jack.
|
|
ROD
No.
|
Length
|
Grip
Length
|
Line
|
Lure
wt
|
Weight
|
MAX
LOAD
|
Pack
Length
|
|
KGS-
510L
|
5'10
"
|
460mm
|
-
16lb. (PE4 number)
|
-
48g
|
164g
|
5kg
(45°)
3kg (90°)
|
140cm
|
|
KGS-
68M
|
6'8
"
|
570mm
|
-
16lb. (PE4 number)
|
-
60g
|
203g
|
6kg
(45°)
4kg (90°)
|
154cm
|
|
KGS-
70MH
|
7'
|
600mm
|
-
20lb. (PE5 number)
|
-
100g
|
266g
|
6.5kg
(45°)
5kg (90°)
|
161cm
|
- All type grip
removal and re-installation type 1 piece specifications
|
- Blank material: It
is low, the medium elastic graphite + high elastic Kevlar graphite. The bat guide in boundary, as for the blank
colour in the sea surface bright/fresh the metallic silver colour
which is obtained
|
|
|
- Guide: All the type
Fuji Sic guide installing. As for 510L 68M in top guide and
bat guide as for ocean guide and other things single foot
guide. 70MH installing the ocean guide with the double
lapping.
|
|
|
- Grip: As for grip
EVA grip of all the type removal and re-installation types.
As for reel seat nonslip process rise lock specification
|
|
|
- Part: The metal
ring adoption which designates the blue as keynote (the
front grip section)
|
|
|
|
